Specifications:
- Product Type: 7-day digital fused spur timeswitch for programmable control of fixed electrical appliances.
- Switching Capacity:
- Resistive load: 13 A (max 3 kW)
- Inductive load: 2 A max
- Voltage-free SPDT switch contacts (changeover)
- Programming Options:
- Up to 20 ON/OFF events per week
- Individual day or block day programming
- 1-minute switching resolution
- Power Supply: 230 V AC, 50 Hz
- Fuse Rating: Replaceable 13 A BS1362 fuse included
- Display Type: Backlit digital LCD showing time, day, and programme status
- Manual Control: Auto, permanent ON/OFF modes with manual override
- Battery Backup: Rechargeable memory backup retains settings during power outages
- Installation Type: Standard UK fused spur wall box (surface or flush mount)
- Construction Material: Durable, flame-retardant polycarbonate casing
- Ingress Protection Rating: IP20 – suitable for indoor environments
- Operating Temperature Range: 0 °C to +40 °C
- Dimensions: Approx. 85 mm (H) × 85 mm (W) × 50 mm (D)
- Certifications: CE and UKCA compliant; meets BS EN standards
- Warranty: 3-year manufacturer’s guarantee
Timeguard FST77N 7 Day Digital Fused Spur Timeswitch
Precision Timing with a Sleek, Built-In Design
The Timeguard FST77N 7 Day Digital Fused Spur Timeswitch gives you total control over your energy use with a clean, flush-mounted solution. Designed to replace a standard fused spur, it combines 7-day digital programming with a 13A fused connection, making it ideal for fixed appliances such as immersion heaters, towel rails, or panel heaters. It fits neatly into your décor while delivering precise and programmable functionality.
Smarter Scheduling for Daily Efficiency
With 24-hour and 7-day programming options, the FST77N lets you customise on/off times to suit your daily routine. Up to 20 on/off switching programmes can be set per week, allowing you to reduce waste and power only when needed. It features a large digital display with intuitive controls, making scheduling easy and accurate.
Safety, Style, and Energy Savings
Fitted with a 13A fuse and a manual override, this timeswitch is designed for long-lasting performance and safety. It ensures peace of mind for controlling electric heating, water heaters, or other fixed-load devices. Housed in a stylish white casing, the FST77N complements any interior while helping reduce energy costs by automating your schedule.
