Product benefits Attractive and functional design Can easily be moved to where light is needed thanks to battery operation Economical operation due to low power consumption Accessories for flexible mounting options included
TECHNICAL DATA
| Nominal wattage |
0.23W |
| Nominal voltage |
4,5 V |
| Mains frequency |
0 Hz |
| Max. no. of lum. on circuit break. B16 A |
- |
| Max. no. of lum. on circuit break. C16 A |
- |
| Max. no. of lum. on circuit break. C10 A |
- |
| Protection class |
III |
| Operating mode |
Battery |
PHOTOMETRICAL DATA
| Luminous flux |
10 lm |
| Luminous efficacy |
43 lm/W |
| Colour temperature |
7000 K |
| Light color (designation) |
Cool White |
| Colour rendering index Ra |
> 80 |
| Beam angle |
70 ° |
DIMENSIONS & WEIGHT
| Diameter |
68.00 mm |
| Height |
22.00 mm |
| Width |
67 mm |
| Product weight |
83.00 g |
MATERIALS & COLORS
| Product colour |
Silver |
| Housing colour |
Silver |
| Body material |
Acrylonitrile butadiene styrene (ABS) |
| Mercury content |
0.0 mg |
APPLICATION & MOUNTING
| Ambient temperature range |
-20…+30 °C |
| Type of protection |
IP20 |
| Dimmable |
No |
| Mounting type |
Surface |
| Mounting location |
Wall |
| Application environment |
Indoor |
| Adjustable |
No |
| LED module replaceable |
Not replaceable |
| With light source |
Yes |
LIFESPAN
| Lifespan L70/B50 at 25 °C |
20000 h |
EMERGENCY LIGHTING
| Nominal voltage of battery |
1.5 V |
