Product benefits
Attractive and functional design
Economical operation due to low power consumption
Easy and fast mounting on nearly every surface (adhesive tape or screws)
Accessories for flexible mounting options included
ELECTRICAL DATA
| Nominal wattage |
1.70 W |
| Nominal voltage |
4,5 V |
| Mains frequency |
0 Hz |
| Nominal current |
55 mA |
| Max. no. of lum. on circuit break. B16 A |
- |
| Max. no. of lum. on circuit break. C16 A |
- |
| Max. no. of lum. on circuit break. C10 A |
- |
| Protection class |
III |
PHOTOMETRICAL DATA
| Luminous flux |
105 lm |
| Luminous efficacy |
62 lm/W |
| Color temperature |
4000 K |
| Light color (designation) |
Cool White |
| Color rendering index Ra |
> 80 |
| Standard deviation of color matching |
≤6 sdcm |
DIMENSIONS & WEIGHT
| Diameter |
86.00 mm |
| Height |
47.00 mm |
| Product weight |
136.00 g |
MATERIALS & COLORS
| Product color |
Silver |
| Housing color |
Silver |
| Body material |
Polycarbonate (PC)|Acrylonitrile butadiene styrene (ABS) |
| Mercury content |
0.0 mg |
APPLICATION & MOUNTING
| Ambient temperature range |
-20…+40 °C |
| Temperature range at storage |
-20…+60 °C |
| Type of protection |
IP20 |
| Dimmable |
No |
| Mounting type |
Surface |
| Mounting location |
Wall |
| Application environment |
Indoor |
| LED module replaceable |
Not replaceable |
| With light source |
Yes |
LIFESPAN
| Lifespan L70/B50 at 25 °C |
25000 h |
SENSOR
| Type of sensor |
Light, Motion |
| Sensor technology |
Passive infrared (PIR) |
EMERGENCY LIGHTING
| Nominal voltage of battery |
1.5 V |
CERTIFICATES & STANDARDS
| Standards |
CE, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" |
No |
